• name: Low cost metal polishing machine for brass rod
  • number: 1. polishing machine
  • Shelf time: 2016-11-30
  • Views : 10
  • 市场价:
  • 零售价:
  • Sold amount: 0Piece
  • Comment Information
  • the number of :  购买数量不能低于最少订购数量!

immediate purchase immediate inquiry Favorite QQ chat Friends Recommend

 Low cost metal polishing machine for brass rod

This machine can straighten materials:brass tube (rod),Bronze tube (bar),aluminum bar,copper bar.

model Product size Precision motor power(kw)
TP2A 5-20dia 0.1mm/100mm 5.5
TP2B 10-45dia 0.2mm/100mm 7.5
TP2C 15-70dia 0.2mm/100mm 11



  2 wheel precise straightening polishing machine2A.jpg  2 wheel precise straightening polishing machine3A.jpg

Related machine

1.Melting furnace+holding furnace

This conjoined furnace control by two electric boxes,double oven style could feeding behind, in front of furnace could keep temperature and casting,holding furnace with multiaspect mold installation function.

low cost metal polishing machine for brass rod

This conjoined furnace control by two electric boxes, double oven style could feeding behind, in front of furnace could keep temperature and casting, holding furnace with multiaspect mold installation function.

Model  Power(kw) Melting Rate Capacity(T)
300 75+45 300 1.0+1.8
500 120+75 500 1.6+2.5
750 180+75(120) 750 2.5+4
1000 240+120 1000 3.5+5

2.Vertical type 4 roller casting machine

low cost metal polishing machine for brass rod



model  casting speed(m/s) casting diameter motor power(kw)
SYO-70 0-0.035 5-70dia 2.2
SYO-100 0-0.035 10-100dia 3
SYO-120 0-0.035 60-120dia 4
SYO-160 0-0.035 80-160dia 5.5
SYO-200 0-0.05 10-200dia 7.5

3.Pneumatic cutting machine

This machine uses double motor box,the main control box electrical fault,manually using the emergency electrical box,without impacting production,cut to exact length adjustable feed more durable stability and tool.

model Specification Production speed Device power Air pressure
Q65 Φ6-65 10s/time 3kw 0-1MPA
Q80 Φ10-80 25s/time 4kw 0-1MPA
Q120 Φ20-120 32s/time 5.5kw 0-1MPA
Q160 Φ30-160 45s/time 7.5kw 0-1MPA



low cost metal polishing machine for brass rod

Packaging & Shipping

.jpg

Contact us

if you are interested in this machine, please tell me your requirement, we will recommend suitable machine for you.Linda3_.png



If you come to china,we can take you to see our customer’s plant,

If you too busy not come to china,please contact me,you will see our operation video.
